Knob trim is specific rather than obsolete, and the first question on any knob order is whether the opening permits it. Shop Sargent cylindrical knob locks across commercial functions, with conventional and interchangeable core keying. In stock at Commercial Door Hardware and shipping the same day.
Which Sargent Lines Offer Knob Trim
|
Line |
Knob trim |
Notes |
|---|---|---|
|
6 Line |
Yes |
Knob and lever options |
|
7 Line |
Yes |
Knob and lever options |
|
10, 11, 10X Lines |
Primarily lever |
Confirm knob availability by configuration |
Confirm knob availability, trim designations and grade for your specific configuration against Sargent's documentation. Our Sargent 6 Line Locks collection covers that line in detail.
Function Guide
|
Function |
Outside |
Inside |
Typical opening |
|---|---|---|---|
|
Passage |
Always operates the latch |
Always free |
Corridors and closets |
|
Privacy |
No key; emergency release |
Locks by button or turn |
Restrooms and private rooms |
|
Office |
Locked and unlocked by key or button |
Always free |
Offices and suites |
|
Entrance |
Locked and unlocked by key |
Always free |
Suite entrances |
|
Classroom |
Key locks and unlocks outside knob |
Always free |
Classrooms and training rooms |
|
Storeroom |
Always locked; key retracts latch |
Always free |
Storerooms and utility rooms |
Note the inside column. Free egress applies on every standard function, and that's a code requirement rather than a feature. Confirm exact function designations against Sargent's documentation.
One function error worth flagging: privacy is not security. Privacy functions are designed to be released from outside in an emergency, usually with a simple tool. That's correct for a restroom and wrong for any room holding something confidential; those need office or storeroom function.
Keying Options
|
Option |
Supplied |
Best for |
|---|---|---|
|
Conventional key-in-knob cylinder |
Cylinder and keys |
Standalone openings and conventional systems |
|
Keyed to your existing Sargent system |
Pinned to your keying |
Adding openings to a Sargent building |
|
Less cylinder |
Prepped, no cylinder |
Facilities fitting their own |
|
Interchangeable core prep |
Prepped, no core |
Buildings on core systems |
|
Non-keyed |
No cylinder |
Passage and privacy functions |
The cylinder on a knob lock sits inside the knob itself. See our Sargent Key In Cylinders collection, and Sargent Interchangeable Cores for core systems.
Available Finishes
|
Code |
Finish |
Notes |
|---|---|---|
|
626 / US26D |
Satin chrome |
The most widely stocked |
|
605 / US3 |
Bright brass |
Common on older knob installations |
|
606 / US4 |
Satin brass |
Satin brass schedules |
|
612 / US10 |
Satin bronze |
Bronze schedules |
|
613 / US10B |
Oil rubbed bronze |
Darker bronze schedules |
|
619 / US15 |
Satin nickel |
Nickel schedules |
|
625 / US26 |
Bright chrome |
Polished chrome schedules |
|
630 / US32D |
Satin stainless steel |
Frequently cleaned areas |
-
Satin hides handling marks far better than polished on knobs specifically, because the entire surface is gripped rather than just a lever's top edge.
-
On older Sargent knob buildings, 605 bright brass and 612 satin bronze are frequently what's installed. Match what's there, not the current default.
-
626 satin chrome carries the deepest stock.
-
Match across the opening, including hinges, closer and any kick or push plate.
-
Availability varies by function and trim; confirm on the product page.
Key Features
-
Full commercial function range from passage to storeroom.
-
Knob trim for openings where a lever isn't wanted or doesn't survive.
-
No handing, since knobs are symmetrical.
-
Standard cylindrical prep for fast installation and replacement.
-
Conventional and core keying options.
-
Keyed to your existing Sargent system on request.
-
Older finishes available for matching existing installations.
-
Serviceable, with latches, springs and trim available separately.
Benefits
-
Matches buildings fitted throughout with knobs, avoiding a partial retrofit.
-
Minimal leverage for openings where levers get destroyed.
-
No handing to get wrong on order or installation.
-
Installs in standard bored prep, so replacement is quick.
-
Keeps openings in the building's key system.
-
Finish matching for older installations.
-
Parts-level repairs rather than lock replacement.
-
Ready to ship. In-stock locks ship the same day.
Applications
-
Buildings fitted throughout with knob hardware.
-
Abuse-prone openings where levers have been breaking, requirements permitting.
-
Service, plant and mechanical spaces, subject to applicable requirements.
-
Restoration and historic projects.
-
Restrooms using privacy functions.
-
Storerooms and utility rooms using storeroom functions.
-
Corridors and closets using passage functions.
-
Like-for-like replacements on existing knob openings.
